GS105PE¶

Port map as the library addresses these ports — schematic, not a faceplate layout.

A 5-port “Smart Plus” switch (Gen-2 Broadcom BCM53125) — a genuinely distinct SKU from the GS305EP, not a rebadge. No SNMP agent, so NSDP and the web UI only.

At a glance¶

Field	Value
Registry key	`gs105pe`
Product name	GS105PE
Class	plus
Ports	5
PoE (PSE) ports	0
Backends	`NSDP`, `HTTP`
SNMP vendor subtree	`none (standard MIBs only)`
MAC/FDB table	no

Live-verified 2026-07-21 against real units at 10.1.5.29 and .30, firmware V1.6.0.x. Seed: seed_gs105pe().

What works, over which protocol¶

Operation	What it does	`NSDP`	`HTTP`
`get_ports`	Per-port link/admin status	✓	✓
`get_stats`	Per-port octet/packet counters	✓	✓
`get_vlans`	VLAN list with tagged/untagged members	✓	✓
`get_pvids`	Per-port PVID	✓	✓
`get_lldp`	LLDP neighbour table	— [gs105pe-1]	— [gs105pe-2]
`get_macs`	MAC/FDB forwarding table	— [gs105pe-3]	— [gs105pe-4]
`get_poe`	Per-port PoE status and power draw	— [gs105pe-5]	— [gs105pe-6]
`get_sensors`	Fan/PSU/temperature sensors	— [gs105pe-7]	— [gs105pe-8]
`get_mgmt_ip`	Management IP configuration	✓	✓
`get_hostname`	The switch’s host name	✓	✓
`get_users`	Local login accounts and their access level	— [gs105pe-9]	— [gs105pe-10]
`get_services`	Which management services (http/https/telnet/ssh) are enabled	— [gs105pe-11]	— [gs105pe-12]
`get_syslog`	Remote-logging configuration and collectors	— [gs105pe-13]	— [gs105pe-14]
`nsdp_device`	Full NSDP device record	✓	— [gs105pe-15]
`set_port_enabled`	Bring a port up or down	— [gs105pe-16]	— [gs105pe-17]
`set_poe`	Enable or disable PoE on a port	— [gs105pe-18]	— [gs105pe-19]
`cycle_poe`	Power-cycle a PoE port	— [gs105pe-18]	— [gs105pe-20]
`clear_poe_fault`	Clear a latched PoE fault	— [gs105pe-18]	— [gs105pe-21]
`set_port_description`	Set or clear a port’s description	✓	— [gs105pe-22]
`set_port_speed`	Force a port’s speed/duplex, or restore auto-negotiation	— [gs105pe-23]	— [gs105pe-24]
`set_flow_control`	Turn IEEE 802.3x flow control on or off for a port	— [gs105pe-25]	— [gs105pe-25]
`set_pvid`	Set a port’s PVID	✓	✓
`set_vlan_membership`	Set a port tagged/untagged/excluded on a VLAN	✓	✓
`create_vlan`	Create a VLAN	✓	✓
`delete_vlan`	Delete a VLAN	✓	✓
`set_mgmt_ip`	Set the management IP/mask/gateway	✓	— [gs105pe-26]
`set_hostname`	Set the switch’s host name	✓	— [gs105pe-27]
`set_syslog_enabled`	Turn remote logging on or off	— [gs105pe-28]	— [gs105pe-28]
`add_syslog_collector`	Add a remote syslog collector	— [gs105pe-29]	— [gs105pe-29]
`remove_syslog_collector`	Remove a remote syslog collector	— [gs105pe-30]	— [gs105pe-31]
`upload_certificate`	Upload an HTTPS certificate over the web UI	— [gs105pe-32]	— [gs105pe-33]
`upload_certificate_scp`	Deploy an HTTPS certificate via FASTPATH `copy scp://`	— [gs105pe-34]	— [gs105pe-34]

[gs105pe-1]

NSDP has no LLDP neighbour tag (measured by an exhaustive NSDP tag sweep of a real GS110EMX (10.1.5.25, firmware 1.0.2.8, 2026-07-30) covering every tag in the 16-bit space; see nsdp_read.py for the full tag inventory)

[gs105pe-2]

model ‘gs105pe’ web UI has no page for get_lldp (LLDP neighbour table)

[gs105pe-3]

NSDP has no MAC/FDB table tag (measured by an exhaustive NSDP tag sweep of a real GS110EMX (10.1.5.25, firmware 1.0.2.8, 2026-07-30) covering every tag in the 16-bit space; see nsdp_read.py for the full tag inventory)

[gs105pe-4]

model ‘gs105pe’ web UI has no page for get_macs (MAC/FDB forwarding table)

[gs105pe-5]

NSDP has no PoE status tag (measured by an exhaustive NSDP tag sweep of a real GS110EMX (10.1.5.25, firmware 1.0.2.8, 2026-07-30) covering every tag in the 16-bit space; see nsdp_read.py for the full tag inventory); use the HTTP backend for PoE

[gs105pe-6]

model ‘gs105pe’ web UI has no page for get_poe (Per-port PoE status and power draw)

[gs105pe-7]

NSDP has no environmental-sensor tag (measured by an exhaustive NSDP tag sweep of a real GS110EMX (10.1.5.25, firmware 1.0.2.8, 2026-07-30) covering every tag in the 16-bit space; see nsdp_read.py for the full tag inventory)

[gs105pe-8]

model ‘gs105pe’ web UI has no page for get_sensors (Fan/PSU/temperature sensors)

[gs105pe-9]

get_users is served only over CONSOLE, HTTP, SSH, TELNET

[gs105pe-10]

model ‘gs105pe’ web UI has no page for get_users (Local login accounts and their access level)

[gs105pe-11]

get_services is served only over CONSOLE, HTTP, SSH, TELNET

[gs105pe-12]

model ‘gs105pe’ web UI has no page for get_services (Which management services (http/https/telnet/ssh) are enabled)

[gs105pe-13]

get_syslog is served only over CONSOLE, HTTP, SNMP, SSH, TELNET

[gs105pe-14]

model ‘gs105pe’ web UI has no page for get_syslog (Remote-logging configuration and collectors)

[gs105pe-15]

nsdp_device is served only over NSDP

[gs105pe-16]

per-port admin-enable over NSDP is UNPROVEN on these Plus models: the measured tag inventory (GS110EMX fw 1.0.2.8) has two candidate per-port config tags (0x0800, 0x9400) whose semantics were never settled – no write has been attempted against either, and a wrong guess can drop the port’s link. Use the HTTP backend, whose port-settings page IS grounded

[gs105pe-17]

model ‘gs105pe’ web UI has no page for set_port_enabled (Bring a port up or down)

[gs105pe-18] (1,2,3)

NSDP has no PoE control tag (measured by an exhaustive tag sweep of a real GS110EMX, 10.1.5.25 fw 1.0.2.8, 2026-07-30 – see nsdp_read._SWEEP); use the HTTP backend for PoE

[gs105pe-19]

model ‘gs105pe’ web UI has no page for set_poe (Enable or disable PoE on a port)

[gs105pe-20]

model ‘gs105pe’ web UI has no page for cycle_poe (Power-cycle a PoE port)

[gs105pe-21]

model ‘gs105pe’ web UI has no page for clear_poe_fault (Clear a latched PoE fault)

[gs105pe-22]

model ‘gs105pe’ web UI has no page for set_port_description (Set or clear a port’s description)

[gs105pe-23]

set_port_speed is served only over CONSOLE, HTTP, SSH, TELNET

[gs105pe-24]

model ‘gs105pe’ web UI has no page for set_port_speed (Force a port’s speed/duplex, or restore auto-negotiation)

[gs105pe-25] (1,2)

set_flow_control is served only over CONSOLE, SSH, TELNET

[gs105pe-26]

model ‘gs105pe’ web UI has no page for set_mgmt_ip (Set the management IP/mask/gateway)

[gs105pe-27]

model ‘gs105pe’ web UI has no page for set_hostname (Set the switch’s host name)

[gs105pe-28] (1,2)

set_syslog_enabled is served only over CONSOLE, SNMP, SSH, TELNET

[gs105pe-29] (1,2)

add_syslog_collector is served only over CONSOLE, SSH, TELNET

[gs105pe-30]

remove_syslog_collector is served only over CONSOLE, HTTP, SNMP, SSH, TELNET

[gs105pe-31]

model ‘gs105pe’ web UI has no page for remove_syslog_collector (Remove a remote syslog collector)

[gs105pe-32]

upload_certificate is served only over HTTP

[gs105pe-33]

model ‘gs105pe’ web UI has no page for upload_certificate (Upload an HTTPS certificate over the web UI)

[gs105pe-34] (1,2)

upload_certificate_scp is served only over CONSOLE, SSH, TELNET

Measured behaviour¶

Zero PoE ports — confirmed, not assumed. The product is marketed with “PoE pass-through”, which means it can be powered over PoE; that is not a claim to source power. The web UI’s getPoePortStatus.cgi returns HTTP 404 on a real unit, so it exposes no PSE status page at all, and poe_port_count is 0.

No MAC/FDB table over any interface. Not NSDP, not the web UI — a confirmed firmware limitation rather than something merely unread.

Two real NSDP bugs surfaced here, both fixed: parse_device wrongly treated the MODEL TLV as optional, and PORT_MIRRORING is variable-width across firmware versions rather than the fixed size the parser assumed.

Protocols¶

NSDP — the default backend; reports MODEL GS105PE and 5 ports.
HTTP web UI — the MERGE_HASH_CGI scheme with the GS105PE page dialect.
